FloodSafe® Inflow Preventer

The FloodSafe® Inflow Preventer is a revolutionary system that works with air valves and provides unrivaled protection of potable water systems from contamination. By preventing water from passing through the FloodSafe®, contaminated floodwater or water that has been compromised by intentional tampering are prohibited from entering the air valve outlet and are subsequently unable to enter the system.

Flood Safe Valve

Product Overview

  • Available in sizes 1" - 16"
  • Piped to an outlet for an air valve
  • Protects potable water systems from environmental and malicious contamination
  • Field Testing Capability - field test kit
  • Low Pressure Shut Off
  • Added Protection - dual float checks
  • Manufactured under a certified ISO 9001 quality system

Certifications

Features

  • Cross Contamination Control
  • Adaptable to existing air valve installations
  • Dual Chambers - Upper Chamber is designed as a back up
  • Dual Float Checks - Designed to assure rapid closure upon the entry of fluid into the chamber.
  • Resilient Seat - patented resilient seats are specially designed and formulated to assure drop tight closure at low pressures.
  • Test Ports - Provides for independent testing of both chambers
  • Basket Screen - prevents debris from entering
  • Cover - Port sized to allow for full venting capacity of air valve or vent
  • Optional Field Test Kit - Allows testing of valve in the field

Specifications

Valve Size Product Description Drawing Number
1" - 16" 1300 FloodSafe® Inflow Preventor VM-1300-S

Materials of Construction

Valve Size Product Description Drawing Number
1" - 16" 1300 FloodSafe® Inflow Preventor VM-1301-M

Dimensions

Valve Size Product Description Drawing Number CAD Version
1" - 16" 1300 FloodSafe® Inflow Preventor VMC-1301 CAD-1301
1" - 16" 1300 FloodSafe® Inflow Preventor Field Test Kit VMC-1301FT CAD-1301FT

Manuals

Valve Size Product Description Drawing Number
1" - 16" FloodSafe® Inflow Preventer FS-OM1

Technical Data

Product Description Drawing Number CAD Version
Protecting Drinking Water Pipelines White Paper
Venting Capacities SS-2144
ASSE Certification SS-2427
FloodSafe® Inflow Preventer PDF CAD
FloodSafe® Field Test Kit PDF CAD
Vault Installation PDF CAD

Brochures
